43GR-FAS25SL

♦常備庫存型號
50kA,熱磁式，過載可調-短路可調，3 -極
320 312..320 1920..3200 85 85 50 50 35

35 20 20 15 15 ■♦140EX-L5F3-D32
400 320..400 2400..4000 85 85 50 50 35

35 20 20 15 15 ♦140EX-L5F3-D40
500 400..500 3000..5000 65 65 35 35 25

25 18 18 10 10 ♦140EX-L5F3-D50
630 504..630 3780..6300 65 65 35 35 25

25 18 18 10 10 ♦140EX-L5F3-D63
♦常備庫存型號
35kA,熱磁式，過載可調-短路可調，4 -極
320 312..320 1920..3200 65 65 35 35 25

25 15 15 8 8 ■♦140EX-L3F4-D32
400 320..400 2400..4000 65 65 35 35 25

25 15 15 8 8 ♦140EX-L3F4-D40
500 400..500 3000..5000 60 60 35 35 25

25 10 10 8 8 ♦140EX-L3F4-D50
630 504..630 3780..6300 60 60 35 35 25

25 10 10 8 8 ♦140EX-L3F4-D63

43GR-FAS25SL

♦常備庫存型號
50kA,熱磁式，過載可調-短路可調，4 -極
320 312..320 1920..3200 85 85 50 50 35

35 20 20 15 15 ■♦140EX-L5F4-D32
400 320..400 2400..4000 85 85 50 50 35

35 20 20 15 15 ♦140EX-L5F4-D40
500 400..500 3000..5000 85 85 50 50 35

35 25 25 10 10 ♦140EX-L5F4-D50
630 504..630 3780..6300 85 85 50 50 35

35 25 25 10 10 ♦140EX-L5F4-D63
♦常備庫存型號
630A, L-型
35kA,電子式，可調的：L, S, I & G故障保護，3 -極
額定 動作電流 In [A] 可調范圍[A] 分斷能力[kA]


熱脫扣 Ir延遲時間 220-240V 380-415V

500V 550V 660V
Ir = (0.4..1.0)In @ 6 x Ir Icu Ics Icu Ics

Icu Ics Icu Ics Icu Ics 產品目錄號
160 64..160 10 sec 65 65 35 35 25 25 15

15 8 8 ♦140EX-L3I3-D16
250 100..250 10 sec 65 65 35 35 25 25

15 15 8 8 ♦140EX-L3I3-D25
400 160..400 10 sec 60 60 35 35 25 25

10 10 8 8 ♦140EX-L3I3-D40
630 252..630 10 sec 60 60 35 35 25 25

10 10 8 8 ♦140EX-L3I3-D63
